说明：
■导体使用单股或绞线32～10AWG镀锡铜
■无卤照射PE绝缘
■额定温度：150℃
■额定电压：300V
■使用标准厚度，易剥，截断容易。
■可通过ULVW-1及CUL FT1/FT2，垂直燃烧测试或水平燃烧测试
应用：
■适用于多种家用电器、照明灯具、电子设备等引出连接线
| UL Style &CSA Type |
Conductor 导体 |
Insulation Thickness |
Overall Dimeter |
Stand Put-up 标准长度 |
Conductor Resistance at 20℃导体电阻 |
||
| 线号 | 线数/线径 | 绝缘厚度 | 完成外径 | 英制 | 公制 | ||
| AWG | No/mm | mm | mm | Ft/coil | M/Coil | Ω/KM | |
| UL3385 （Stranded) 绞线 |
32 | 7/0.08 | 0.41 | 1 | 2000 | 610 | 586 |
| 30 | 7/0.10 | 1.1 | 381 | ||||
| 28 | 7/0.127 | 1.2 | 239 | ||||
| 26 | 7/0.16 | 1.3 | 150 | ||||
| 24 | 11/0.16 | 1.4 | 94.2 | ||||
| 22 | 17/0.16 | 1.6 | 59.4 | ||||
| 20 | 21/0.178 | 1.8 | 36.7 | ||||
| 18 | 34/0.178 | 2.1 | 23.2 | ||||
| 16 | 26/0.25 | 2.4 | 14.6 | ||||
| 14 | 21/0.178 | 2.8 | 8.96 | ||||
| 12 | 34/0.178 | 3.4 | 1000 | 305 | 5.64 | ||
| 10 | 26/0.25 | 4 | 3.55 | ||||
| UL3385（Top-coated) 先绞后镀 |
28 | 7/0.127 | 1.2 | 2000 | 610 | 239 | |
| 26 | 7/0.16 | 1.3 | 150 | ||||
| 24 | 7/0.20 | 1.4 | 94.2 | ||||
| 22 | 7/0.25 | 1.6 | 59.4 | ||||
| UL3385 （Solid) 单股 |
28 | 1/0.32 | 1.1 | 239 | |||
| 26 | 1/0.404 | 1.2 | 150 | ||||
| 24 | 1/0.511 | 1.3 | 94.2 | ||||
| 22 | 1/0.643 | 1.4 | 59.4 | ||||
| 20 | 1/0.813 | 1.6 | 36.7 | ||||
| 18 | 1/1.024 | 1.8 | 23.2 | ||||
